    Customizable BIPV Solar Panels Class A Mono Solar Cell 200watt 320W

    Ask Lasest Price
    Brand Name : Rixin
    Model Number : RXJJ-320
    Certification : TUV CE
    Price : BIPV Solar Panels
    Payment Terms : L/C, T/T
    Supply Ability : 3GW/year
    Delivery Time : 7-20 working days
    • Product Details
    • Company Profile

    Customizable BIPV Solar Panels Class A Mono Solar Cell 200watt 320W

    Customizable BIPV Solar Panels Class A Mono Solar Cell 200watt 320W Solar Module


    Self-branded

    Formed in 2001,has a total of 500 employees. It has two manufacturing bases, with area 180000㎡ and fully automatic production lines.

    Industry Experience

    Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies.

    Competitive products

    High efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

    Professional Team

    Professional saling service and after-sale service.

    R&D staff is over 10% employees.

    Perfect logistics and warehousing services.


    158.75mm PERC mono bifacial solar panel-DDM(P)315~320
    Electrical performance parameters
    Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5
    ModelDDM(P)315DDM(P)320
    Maximum power(Pm/Wp)315320
    Open circuit voltage (Voc/V)40.240.4
    Short circuit current (Isc/A)9.9110.02
    Peak power voltage (Vmp/V)33.333.4
    Peak power current (Imp/A)9.469.58
    Module efficient(%)18.819.1
    Electrical performance parameters (back)
    ModelDDM(P)315DDM(P)320
    Maximum power (Pmax/W)237241
    Open circuit voltage (Voc/V)39.940.1
    Short circuit current (Isc/A)7.587.64
    Peak power voltage (Vmp/V)34.234.3
    Peak power current (Imp/A)6.957.03
    Module efficient(%)14.114.4
    Different power gains (take 320W as an example)
    Power gain5%10%15%25%
    Maximum power (Pmax/W)336352368400
    Open circuit voltage (Voc/V)40.440.440.440.4
    Short circuit current (Isc/A)10.6611.1711.6812.69
    Peak power voltage (Vmp/V)33.433.433.433.4
    Peak power current (Imp/A)10.0610.5411.0211.98
    Mechanical parameters
    Cell Nos & array60(6*10)
    Diodes No.3
    Junction box/ConnectorIP68, split junction box
    Cable4mm2, 300mm wire length, the length can be customized
    Module weight (kg)30
    Module dimension (L*W*H)(mm)1676*1002*7.5 (including junction box thickness 25)
    Packing33pcs/pallet
    Temperature Coefficient
    Short circuit current (Isc)+0.05%/℃
    Open circuit voltage (Voc)-0.29%/℃
    Peak power (Pmax)-0.39%/℃
    Quality parameters
    Component operating temperature range (℃)-40~+85
    TpyeApplicationFeature
    roofingCurtain wall

    Photovoltaic wind

    ow

    SunroomCanopy/sunshadeFence

    Assembled photovoltaic tile




    Waterproof, Easy to installation and maintenance


    Crystal silicon double-sided laminated glass







    Double sided power generation, high power generation and long power generation life


    Ordinary crystal silicon laminated glass







    Long power generation life


    Film laminated glass








    Great appearance, adjustable light transmittance


    Crystal silicon double-sided insulating glass





    Double sided power generation, high power generation and long power generation life


    Ordinary crystalline silicon insulating glass





    Excellent thermal insulation performance


    Membrane insulating glass





    Great appearance, adjustable light transmittance


    High efficiency crystalline silicon module



    Building Additions
