Roof Or Ground BIPV Solar Panel High Efficiency 330 Watt

Ask Lasest Price
Brand Name :	Rixin
Model Number :	MBG330
Certification :	CE\IEC\TUV\ISO14001
Price :	negotiation
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	3GW/YEAR
Delivery Time :	7-10 working days after payment

Add to Cart

Product Details
Company Profile

Roof Or Ground BIPV Solar Panel High Efficiency 330 Watt

Rixin Hot sale BIPV Solar Panel 330Watt Solar Plate High Efficiency Solar Panels China Factory Supplier Price

Characteristics solar panel

1. Manufactured according to international quality and Environment Management System (ISO9001, ISO14001)

2. High efficiency crystalline silicon solar cells

3. High transmission Iow iron tempered glass, strong mechanical resistance

4. Anti-ageing EVA and excellent anti-climate back sheet

5. Anodized aluminum frame improves load resistance capabilities for heavy wind loads.

6. Standard waterproof junction box

7. High endurance to different weather

8. Good and friendly package with less transportation and storage space.

Roof Or Ground BIPV Solar Panel High Efficiency 330 Watt

MBG330~340
Electrical performance parameters
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5
Type	MDG330	MDG335	MDG340
Maximum power(Pm/Wp)	330	335	340
Maximum power voltage(Vmp/V)	37.0	37.1	37.2
Maximum power current(lmp/V)	8.90	9.03	9.14
Open circuit voltage(Voc/V)	45.0	45.1	45.2
Short circuit current(Isc/A)	9.98	10.08	10.18
Module efficient(%)	16.5	16.7	17
NOCT(℃)	45±2℃
Temperature coefficient of Voc	-0.31%/℃
Temperature coefficient of Isc	0.05%/℃
Temperature coefficient of Pm	-0.41%/℃
Power tolerance(W)	0~+5
Mechanical performance parameters
Module dimension (LWH)(mm)	201599635
Module weight (kg)	28
Cable	4mm² negetive300mm, positive300mm
Junction box/Connector	Ip68,split / MC4 compatible
Cell size (mm)	Poly half cell 144(6122)
Packing	30pcs/pallet
Quality parameters
Module working temperature range (℃)	-40~+85
Maximum system voltage(V)	1500DC
System maximum protection current(A)	15
Maximum wind pressure/maximum snow pressure (Pa)	2400/5400

RFQ

Q1 : What about delivery time?

A : Goods : 10-15 working days usually.

Q2 : Can you provide OEM service?

A : Yes,we can.Including customized logo/customized packaging/Graphic customization.

Q3 : Do you test the goods before shipment ?

A : Yes,we have professional QC team to test all the goods before packing.And we will check the packing before shipment.

Q4 : What about the quality warranty?

A : 12-year material & workmanship warranty.

30-year linear power warranty.

Q5: What is you payment terms?

A : We accept T/T bank transfer,L/C, Paypal, Western union and MonryGram.

Q6 :What is your products’ advantage?

A : First ,we own our brand and we have over 20 years produce experience.We have cooperation projects with governments and well-known companies and have won a good reputation.

Self-branded

Formed in 2001,has a total of 500 employees. It has two manufacturing bases, with area 180000㎡ and fully automatic production lines.

Industry Experience

Rixin Technology is a clean energy company as well as one of the China’s leading crystalline silicon solar power companies.

Competitive products

High efficiency Perc mono half-cut bifacial module, BIPV laminated double glass module, Perc mono/poly framed solar panel, solar power system etc, at present, Rixin Technology’s total installed capacity of solar projects exceeds 1GW.

Professional Team

Professional saling service and after-sale service.

R&D staff is over 10% employees.

Perfect logistics and warehousing services.
