Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency

    Buy cheap Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency from wholesalers

    Buy cheap Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency from wholesalers
    • Buy cheap Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency from wholesalers
    • Buy cheap Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency from wholesalers
    • Buy cheap Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency from wholesalers

    Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency

    Ask Lasest Price
    Brand Name : Rixin
    Model Number : DBG365(P)
    Certification : TUV, CE, ISO9001, ISO14001, OHSAS18000
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 3GW/YEAR
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency

    Perc monocrystalline framed solar panel / 365W / 72cells / 24V

    Main Features
    1. Positive power tolerance (0~+5W) guaranteed.
    2. High module conversion efficiency.
    3. Low LID.
    4. Better energy yield with excellent low irradiance performance and temperature coefficient.
    5. Adaptable to harsh environment: passed rigorous salt mist and ammonia tests.
    6. Robust frame(40mm) withstands mechanical loading of 5400Pa for snow load on front and 2400Pa for wind load on rear side.

    Solar Cells

    > High Efficiency PV Cells

    > Appearance Consistency

    > Color sorting ensure consistent appearance on each module

    > Anti-PID


    Electrical performance parameters

    Electrical performance parameters
    STC (AM1.5, 1000W/m², cell temperature 25℃)
    ModelDBG365(P)
    Maximum power (Pm/Wp)365
    Maximum power voltage (Vmp/V)39.3
    Maximum power current (Imp/A)9.29
    Open circuit voltage (Voc/V)48.0
    Short circuit current (Isc/A)9.74
    Module efficiency (%)18.7
    Normal operating cell temperature (NOCT)45±2℃
    Temperature coefficient of Voc-0.30%/℃
    Temperature coefficient of Isc0.059%/℃
    Temperature coefficient of Pm-0.39%/℃
    Power tolerance (W)0~+5

    General performance parameters

    Mechanical performance parameters
    Module dimension (L*W*H) (mm)1956*992*40/45
    Cell dimension(mm)156.75*156.75 PERC mono
    Module weight (kg)23
    Cablecable section-4mm2 length-900mm
    Cell Nos & array72(6*12)
    Packing25pcs/pallet, 22pallets/40HQ, 550pcs/40HQ
    Quality parameters
    Module working temperature range (℃)-40~+85
    Maximum system voltage (V Dc)1000
    System maximum protection current (A)15
    Maximum wind loads/maximum snow loads (Pa)2400/5400
    Hot-spot resistance100% hot-spot free


    Drawing(mm)
    Reliable Weather Proof PERC PV Module 365W 72 Cells 24V High Efficiency

    Quality Warranty
    10-year materials&workmanship warranty
    25-year linear power warranty
