108PCS 10bb Mono Half Cut High Power Solar Panels 400W 405W 410W 415W

    Buy cheap 108PCS 10bb Mono Half Cut High Power Solar Panels 400W 405W 410W 415W from wholesalers

    Buy cheap 108PCS 10bb Mono Half Cut High Power Solar Panels 400W 405W 410W 415W from wholesalers
    • Buy cheap 108PCS 10bb Mono Half Cut High Power Solar Panels 400W 405W 410W 415W from wholesalers

    108PCS 10bb Mono Half Cut High Power Solar Panels 400W 405W 410W 415W

    Ask Lasest Price
    Brand Name : Rixin
    Model Number : SKT400M10
    Certification : TUV, CE, ISO9001, ISO14001, OHSAS18000
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 3GW/year
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    108PCS 10bb Mono Half Cut High Power Solar Panels 400W 405W 410W 415W

    108PCS 10bb Mono Half Cut 400W 405W 410W 415W Solar Panel


    Product Certificates:


    TUV SUD / CE / IEC / TUV NORD / COC / INMETRO


    Management System


    ISO 9001 -- Quality Management System


    ISO 14001 -- Standard for environmental management system


    OHSAS 18001 -- International standard for occupational health and safety accessment system


    Key Features


    10 Busbar Solar Cell -- 10 busbar solar cell adopts new technology to improve the efficiency of modules, offers a better aethestic appearance, making it perfect for rooftop installation


    High Efficiency -- Higher module conversion efficiency( Up to 21.0% ) benefit from passivated rear contact (PERC) technology.


    PID Risistance -- Excellent Anti - PID performance guaranteed limited power degradation for mass production.


    Low-light Performance -- Advanced glass and cell surface textured design ensure excellent performance in low-light environment.


    Severe Weather Resilience -- certified to withstand: wind load (2400 pascal ) and snow load (5400 pasal)


    Durability Against Extreme Environmental Conditions -- Resistance to high salt mist and ammonia.


    Electrical performance parameters

    108PCS 10bb Mono Half Cut 400W 405W 410W 415W Solar Panel
    STC (AM1.5, 1000W/m², cell temperature 25℃)
    ModelSKT400M10
    Maximum power (Pm/Wp)400
    Maximum power voltage (Vmp/V)31.01
    Maximum power current (Imp/A)12.9
    Open circuit voltage (Voc/V)37.07
    Short circuit current (Isc/A)13.79
    Module efficiency (%)20.5
    Normal operating cell temperature (NOCT)45±2℃
    Temperature coefficient of Voc-0.0.275%/℃
    Temperature coefficient of Isc0.045%/℃
    Temperature coefficient of Pm-0.35%/℃
    Power tolerance (W)0~+4.99

    General performance parameters

    Mechanical performance parameters
    Module dimension (L*W*H) (mm)1722*1134*30
    Cell dimension(mm)Mono crystalline 182 mm
    Module weight (kg)20.5
    Cablecable section-4mm2 length-300mm
    Cell Nos & array108(54*2)
    Packing36pcs/pallet, 216/20GP, 936pcs/40HQ
    Quality parameters
    Module working temperature range (℃)-40~+85
    Maximum system voltage (V Dc)1000
    System maximum protection current (A)15
    Maximum wind loads/maximum snow loads (Pa)2400/5400
    Hot-spot resistance100% hot-spot free


    Drawing(mm)





    Quality Warranty
    12-year materials&craft quality assurance


    12-year 90% output power guarantee
    25-year 80% output power guarantee
