Rixin 200watt Mini BIPV Double Glass PV Modules Solar Panels
Polycrystalline
Main Feature
Outstanding module performance
Anti PID
High hot-spot resistance
Double semi-tempered glasses strengthen cracking resistance
Improve heat dissipation
Ensure fire safety performance
Replace polymer back plate with tempered glass, to improve fire
safety perormance
Passed fire safety test grade A
System cost reduction makes more efficiency
Maximum system voltage enhanced to 1500V
Compared with 1000V system, system overall cost reduced greatly
30-year linear power warranty, only 0.5% annual linear degradation
Harsh environment adaptation
High transmittance,anti reflection, self-cleaning coated glass
No aluminum alloy frame, no grounding
Excellent performance on wind & sand resistance, salt mist
resistance, ammonia corrosion resistance
Passsed positive snow loads(5400pa) and wind loads(2400pa)
certification tests.
| Product name | Polycrystalline Silicon Laminated Glass Module |
| Type | RXJJ-MDN210 |
| Electrical parameters | Maximum power (Pm/Wp)* | 210 |
| Power tolerance (%) | ±5 |
| Maximum power voltage (Vmp/V)* | 24.78 |
| Maximum power voltage ( Imp/A)* | 8.48 |
| Open circuit voltage (Voc/V)* | 30 |
| Short circuit current (Isc/A)* | 9.35 |
| Module efficiency ηc(%)* | 13.6 |
| Maximum system voltage(V) | 1500 |
| Working temperature(℃) | -40～85 |
| Temperature coefficient of Pm | -0.41%/℃ |
| Temperature coefficient of Voc | -0.31%/℃ |
| Temperature coefficient of Isc | +0.05%/℃ |
| Mechanical parameters | Fault structure(mm) | 5 Low iron tempered glass+0.76PVB+polycrystalline silicon
cell+0.76PVB+5 tempered glass (3.2+3.2 glass can also be used, the
thickness is reduced and the weight is reduced) |
| Cable | 4mm2/900mm |
| Module dimension (L*W*H)(mm) | 1460mm*1060mm*11mm |
| Module Weight (kg) | 40kg |
| Wind resistance | 2.4kN/m2 |
Rixin Technology is a clean energy company as well as one of the
China’s leading crystalline silicon solar power companies,
committed to change the world by solar energy.
Formed in 2001, the company is headquartered in Wuhan, China and
has a total of 500 employees. It has two manufacturing bases, with
area 180000㎡ and fully automatic production lines. Through its
rational investment and industrial, Rixin Technology has formed an
entire chain including R&D of core technology, manufacturing,
integration and service etc.
With core products covering N-type mono bifacial double glass solar
panel, high efficiency Perc mono double glass solar panel,
mono/poly double glass solar panel, Perc mono/poly framed solar
panel, utility-scale solar power station etc, at present, Rixin
Technology’s total installed capacity of solar projects exceeds
1GW.
Rixin Technology believes that high efficiency crystalline modules
will define the future of PV industry. Based on this strategic
thinking, Rixin Technology specializes in the development of high
efficiency crystalline solar technical roadmap and it has become
one of the largest PV companies in terms of its scale and the
leading expertise in China.
We use top-quality solar cells and EVA,TPT,strengthen glass,seal
silicion etc. Our experienced staffs work together well to
assurance quality under effective ISO system. We have IEC61215,
IEC61730 certificates, CE, to assure our quality. Our products are
exported to Europe, America and other Asian countries with safety
certificates.
With many years development as a trustworthy manufacturer, Rixin
Technology’s products enjoy high reputation in the world market.We
have attended many exibitions each year.
Our value is coordination, innovation, sincerty, service. We will
make unremitting efforts to be your best partner on your path of
the photovoltaic weath.
RFQ
Q1 : What about delivery time?
A : Goods : 10-15 working days usually.
Q2 : Can you provide OEM service?
A : Yes,we can.Including customized logo/customized
packaging/Graphic customization.
Q3 : Do you test the goods before shipment ?
A : Yes,we have professional QC team to test all the goods before
packing.And we will check the packing before shipment.
Q4 : What about the quality warranty?
A : 12-year material & workmanship warranty.
30-year linear power warranty.
Q5: What is you payment terms?
A : We accept T/T bank transfer,L/C, Paypal, Western union and
MonryGram.
Q6 :What is your products’ advantage?
A : First ,we own our brand and we have over 20 years produce
experience.We have cooperation projects with governments and
well-known companies and have won a good reputation.
